If you have other devices to install or remove, do so now. Otherwise, go to
“Completing the installation” on page 109.
Installing drives
Depending on the server model, the server might come with a SATA attached
DVD-ROM drive in bay 1.
The followings are illustrations of the server and the location of the drive bays. Your
hardware might differ, depending on the model.
Note: If the server is configured for RAID operation using a ServeRAID adapter,
you might have to reconfigure your disk arrays after you install drives. See
the ServeRAID adapter documentation for additional information about RAID
operation and complete instructions for using the ServeRAID adapter.
The following illustrations show the location of the drive bays in the 2.5-inch
hot-swap SAS or hot-swap SATA hard disk drive server models.
Figure 7. server with eight 2.5-inch hard disk drives
Chapter 2. Installing optional devices 65
