Installing a CD or DVD drive
To install a CD or DVD drive, complete the following steps:
1. Read the safety information that begins on page v and “Installation guidelines”
on page 22.
2. Turn off the server and peripheral devices, and disconnect the power cords
and all external cables.
3. Unlock the side cover.
4. Remove the side cover (see “Removing the side cover” on page 26).
5. Place your finger on the depression area on the left side of the bezel door and
rotate it away from the server. After you rotate the bezel beyond 90°, pull the
bezel off the server and set it aside.
6. Remove the EMC shield from the bay in which you want to install the drive.
Optical drive
Optical drive
rails
EMC shield
Note: If you are installing a drive that contains a laser, observe the following
safety precaution.
36 System x3400 Types 7973, 7974, 7975, and 7976: User’s Guide
