Icom IC-7300 HF Plus User Manual

3
BASIC OPERATION
3-8
Setting the frequency
Entering a new Band Edge
After you delete or edit the preset band edges, you
can enter a new band edge.
1. Open the “User Band Edge” screen.
2. Select a blank band.
(Example: 10)
3. Enter the lower band edge frequency.
(Example: 51.15)
Rotate
Push
4. Touch [ENT] to save the entered lower band edge
frequency.
5. Enter the upper band edge frequency.
(Example: .75)
6. Touch [ENT] to save the entered upper band edge
frequency.
“User Band Edge” screen
Deleting a Band Edge
To enter a new band edge, rst you must delete a
preset band edge.
L Initially, all band edges are entered. Therefore, you must
rst edit or delete them to enter a new band edge.
L You cannot enter an overlapped frequency or a frequency
that is out of the preset transmit frequency.
1. On the FUNCTION set screen, select “User Band
Edge.”
2. Touch the desired band edge to delete for 1
second.
(Example: 1: 1.800.000 – 1.999.999 MHz)
3. Touch “Delete.”
“User Band Edge” screen
1.800.000 – 1.999.999 MHz is deleted.
D Entering a Band Edge (Continued)
• The selected band edge is deleted and returns to the
previous screen.
• The entered band edge is saved and returns to the
previous screen.
