2 - 6
TUNER CPU
(IC701)
• CTRL UNIT
DC AMP
(IC131)
+5V LINE REGULATOR
(IC801)
DC AMP
(IC41)
PHASE DETECTOR
(IC111)
TX POWER DETECTOR
(D602)
