6 - 1
SECTION 6
MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CHASSIS PARTS] [CHASSIS PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1 6510000370 MR-DS-01 <SSC> 1
J2 6510000370 MR-DS-01 <SSC> 1
SP1 2510000761 SM-C77KY0208 1
MF1 2710000630 FBA08T12HC () 1
W1** 8900019230 OPC-2025 (P1N20L80) 1
W4** 8900019230 OPC-2025 (P1N20L80) 1
W5** 8900015160 OPC-916A (P1N22L120) 1
W6** 8900014070 OPC-1438 (P0.5N40L120) 1
W7** 8900019260 OPC-2028 (P0.5N40L330) 1
W8** 8900019270 OPC-2029 (P1N20L190) 1
W9** 8900017140 OPC-927A (P1N24L100) 1
W10** 8900019290 OPC-2031 (P0.5N30L110) 1
W117** 8970025210 1.5DCOAXIAL250MM C31/C31 1
W119** 8970024401 1.5DCOAXIAL360MM-1 C31/C31 1
W121** 8970024411 1.5DCOAXIAL330MM-1 C31/C31 1
W123** 8970024091 1.5DCOAXIAL210MM-1 C31/C31 1
W125** 8970024291 1.5DCOAXIAL150MM-1 C31/C31 1
W127** 8970025210 1.5DCOAXIAL250MM C31/C31 1
W129** 8970024091 1.5DCOAXIAL210MM-1 C31/C31 1
W131** 8970024730 1.5DCOAXIAL 80MM C31/C31 1
W133** 8970024401 1.5DCOAXIAL360MM-1 C31/C31 1
W135** 8970024201 1.5DCOAXIAL300MM-1 C31/C31 1
W137** 8970024201 1.5DCOAXIAL300MM-1 C31/C31 1
W139** 8970024341 1.5DCOAXIAL190MM-1 C31/C31 1
W141** 8970024082 1.5DCOAXIAL180MM-2 C31/C31 1
W1001** 8600037310 SX3183 P1001*P1002CH 1
W1031** 8600037330 SX3183 P1031*P1032CH 1
W1041** 8600037400 SX3182 P1041*P1042CH 1
W1061** 8600037410 SX3182 P1061*P1062CH 1
W1091** 8600037370 SX3183 P1091*P1092*P1093CH 1
W1101** 8600037380 SX3183 J1101*P1102CH 1
W1121** 8600037390 SX3183 P1121CH 1
W1131** 8900019320 OPC-2034 1
MP1 8010021840 3182 CHASSIS 1
MP2 8110009830 3183 U-COVERASSEMBLY 1
MP3 8110009781 3183 L-COVER-1 1
MP4 8510019470 3183 SHIELD COVER 1
MP6 8930081440 3183 SP S-DAMPER 1
MP7 8810006501 BIND M4 X20 ZK3 4
MP8 8510019490 3183 TUNER PLATE 1
MP9 8510019480 3183 PLL PLATE 1
MP10 8510019510 3183 BPF PLATE 1
MP11 8510019501 3183 BPF CASE-1 1
MP15 8810003361 SETSCREWC M3 X 6 ZC3 2
MP16 8930052450 2355 EARTH PLATE 2
MP18 8810008661 PHBT M3 X 8 NI-ZC3 4
MP19 8930077030 3073 MAIN STAND 2
MP20 8930077040 3073 SUB STAND 2
MP21 8810008661 PHBT M3 X 8 NI-ZC3 2
MP22 8930077020 3073 A-STAND SHEET 2
MP23 8930077490 3073 B-STAND SHEET 2
MP24 8930040590 RUBBER LEG (K) 2
MP25 8930077650 3073 SIDE HANDLE (5) 1
MP26 8810010870 ROUND FLAT M4 X12 ZK3 2
MP27 8930079690 RUBBER STAND (Q) 4
MP28 8820000530 FLANGE BOLT M4 X 8 NI 1
MP29 8850000140 FLAT WASHER M 4 NI BS 2
MP30 8850000430 S-WASHER M 4 NI 1
MP31 8810005771 BIND M3 X 8 ZK3BLACK 12
MP32 8810005771 BIND M3 X 8 ZK3BLACK 6
MP33 8810008661 PHBT M3 X 8 NI-ZC3 22
MP34 8810009651 FLAT BT M3 X 8 NI-ZC3 4
MP35 8810008661 PHBT M3 X 8 NI-ZC3 7
MP36 8810008661 PHBT M3 X 8 NI-ZC3 8
MP37 8810003361 SETSCREWC M3 X 6 ZC3 5
MP38 8810008661 PHBT M3 X 8 NI-ZC3 7
MP39 8810008661 PHBT M3 X 8 NI-ZC3 1
MP40 8930027480 1126 TR-A CLIP Y124 1
MP41 8810008661 PHBT M3 X 8 NI-ZC3 9
MP42 8810008661 PHBT M3 X 8 NI-ZC3 7
MP43 8810008661 PHBT M3 X 8 NI-ZC3 9
MP44 8810008661 PHBT M3 X 8 NI-ZC3 5
MP45 8810005771 BIND M3 X 8 ZK3BLACK 5
MP46 8810008661 PHBT M3 X 8 NI-ZC3 4
MP48 8810008661 PHBT M3 X 8 NI-ZC3 13
MP49 8810007231 SETSCREWH M3 X 8 ZC3 2
MP50 8810007231 SETSCREWH M3 X 8 ZC3 4
MP51 8930075440 3015 RUG SPRING Y1115 2
MP59 8810007231 SETSCREWH M3 X 8 ZC3 2
MP62 8310050190 2355 ANT PLATE 3
MP64 8930080830 THERMAL SHEET (BV)TC300HSV1.4 (5X19.5 1
MP65 8810008661 PHBT M3 X 8 NI-ZC3 4
MP66 8010021630 3183 MAIN CHASSIS 1
MP67 8930079060 3073 DC PLATE 1
MP72 8930080990 3183 FAN SPRING Y1196 1
MP73 8930081060 3183 AL SHEET 1
MP74 8930070510 THERMAL SHEET (BF)TC-600HS-1.4 (14.5X 1
MP93 8510019940 3183 BPF SHIELD PLATE 1
MP94 8930043800 DOUBLE SIDE TAPE (S) 1
MP95 8930082150 SPONGE (KZ) 1
MP96 8950003640 CAOTING CLIP CS-2 (UL) 1
MP97 8950003640 CAOTING CLIP CS-2 (UL) 1
MP98 8930082150 SPONGE (KZ) 1
MP99 8930081420 SPONGE (KX) 1
MP100 8930081420 SPONGE (KX) 1
MP101 8930081420 SPONGE (KX) 1
MP102 8930081420 SPONGE (KX) 1
MP103 8930081420 SPONGE (KX) 1
MP104 8930081420 SPONGE (KX) 1
MP105* 8930043020 RUBBER SHEET (AC) 1
MP108** 8930081420 SPONGE (KX) 1
MP110 8930070510 THERMAL SHEET (BF)TC-600HS-1.4 (14.5X 1
MP111 8930070510 THERMAL SHEET (BF)TC-600HS-1.4 (14.5X 1
[MAIN UNIT]
[CONNECT UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J3* 6510021561 52808-2470 (2490) TAPING 1
J5* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J6* 6510026180 S12B-PH-SM4-TB (LF) (SN) 1
J7* 6510027710 S5B-ZR-SM4A-TF (LF) (SN) 1
J8* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J9* 6510024111 52793-2070 (2090) 1
J10* 6510027500 S11B-PH-SM4-TB (LF) (SN) 1
J11* 6510024111 52793-2070 (2090) 1
J1122* 6510019971 52808-1071 1
J3201 6510018450 TMP-S01X-B1 1
J3203* 6510018301 S2B-ZR-SM4A-TF (LF) (SN) 1
J3621 6510018450 TMP-S01X-B1 1
J3671 6510018450 TMP-S01X-B1 1
J3911 6510018450 TMP-S01X-B1 1
MP2001 8510019780 3183 A-MAIN CASE 1
MP2002 8510019790 3183 B-MAIN CASE 1
MP2003 8930081481 INSULATION SHEET (IA)-1 1
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J101* 6510023720 LGY6501-0600C 1
J151* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J611* 6510023720 LGY6501-0600C 1
J751* 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J1001* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J1002* 6510027040 B12B-PH-SM4-TB (LF) (SN) 1
J1003* 6510025760 B5B-ZR-SM4-TF (LF) (SN) 1
J1101* 6450001641 TCS5044-0141177 1
J1301* 6510023900 LGR4619-7000 1
J1401 6450001130 JPJ2042-01-110 1
[PLL UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J81* 6510019991 52808-2271 (2291) TAPING 1
J501* 6510007020 TMP-J01X-V6 1
J571* 6510007020 TMP-J01X-V6 1
J671* 6510007020 TMP-J01X-V6 1
J701* 6510007020 TMP-J01X-V6 1
J851* 6510007020 TMP-J01X-V6 1
J852* 6510007020 TMP-J01X-V6 1
EP151* 6910002161 CASE-BM7H-LF 1
EP354* 6910002161 CASE-BM7H-LF 1
MP291* 8510019980 3183 B-VCO CASE Y1205 1
MP292 8510019990 3183 B-VCO COVER Y1206 1
MP293 8810008490 SETSCREWH M2.6X 8 NI 2
MP351* 8510019710 3182 PLL CASE Y1187 1
MP701* 8510019710 3182 PLL CASE Y1187 1
To Next Page
