2 - 5
DC-DC CONVERTER
(IC131)
• PA-A UNIT
D/A CONVERTER
(IC431)
S/P CONVERTER
(IC432)
DRIVE AMP
(Q221)
DC AMP
(IC371)
BIAS CONTROLLER
(IC301)
DRIVE AMP
(Q222)
POWER AMP
(Q241)
POWER AMP
(Q242)
PRE-DRIVE AMP
(Q201)
