SPECIFICATIONS
n Specifications
ï General
• Frequency coverage
Analog : 446.00625–446.09375 MHz
Digital : 446.103125–446.196875 MHz
• Mode :
16K0G3E (FM)
14K0F3E (FM)
8K50F3E (FM)
4K00F1D (FM)
• Current drain (at 7.2 V) : TX high 0.5 A max.
Max. audio 350 mA max.
• Power supply requirement : 7.2 V DC nominal
(negative ground)
• Frequency stability : ±0.5 kHz
(–25°C to +55°C)
• Antenna impedance : 50 ø nominal
• Dimensions :
53.0(W) × 195.0(H) × 32.5(D) mm
(Projections not included)
• Weight : Approx. 280 g
ï Transmitter
• Output power : 0.5 W
• Modulation system : Variable reactance frequency
modulation
• Max. frequency deviation : ±2.5 kHz
• Spurious emissions : 0.25 µW or below 1 GHz
1.00 µW above 1 GHz
• Adjacent channel power : 60 dB
• External mic. connector : 3-conductor 2.5 (d) mm/2.2 kø
ï Receiver
• Receive system : Double conversion
superheterodyne
• Sensitivity (20 dB SINAD) : 26.5 dBµV/m
• Squelch sensitivity : 26.5 dBµV/m
• Intermodulation rejection ratio : 86.29 dBµV/m
•
Spurious response rejection ratio
: 91.29 dBµV/m
• Adjacent channel selectivity : 81.29 dBµV/m
• Audio output power : 0.5 W (typical) at 5% distortion
with a 8 ø load
0.6 W (typical) at 5% distortion
with a 6 ø load
• External speaker connector : 2-conductor 3.5 (d) mm/8 ø
All stated specifications are subject to change without notice
or obligation.
