ï Belt clip
To attach the belt clip:
q Release the battery pack if it is attached.
w Slide the belt clip in the direction of the arrow until the belt
clip is locked and makes a ‘click’ sound.
To detach the belt clip:
q Release the battery pack if it is attached.
w Pinch the clip (q), and slide the belt clip in the direction
of the arrow (w).
ï Jack cover
Attach the jack cover when the optional speaker-microphone
or headset is not used.
To attach the jack cover:
q Insert the jack cover into
the [MIC/SP] jack.
w Tighten the screws.
•
Use the supplied screws only.
To detach the jack cover:
e Unscrew the screws using
a phillips screwdriver.
r Detach the jack cover for
the optional speaker-mi
-
crophone or headset con-
nection.
[MIC/SP] jack
Jack cover
e
e
w
q
r
2
1
ACCESSORIES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
