59
SPECIFICA
TION
S AN
D OPTIO
NS
10
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
New2001
■
Options
•
MBF-5
flush
mount
kit
T
o mount the transceiver to a panel.
•
MA-500TR
class
b
ais
transponder
T
o transmit individual DSC calls to a selected
AIS targets.
D
GPS Antenna
•
Frequency :
1575.42 MHz
•
Channel:
66 ch
•
Deferential satellites:
WAAS, EGNOS, MSAS, GAGAN
•
GLONAS receiving frequency:
1602MHz
D
Dimensions
Unit: mm (inch)
66.5 (2.6)
25.8
(1)
84.3 (3.3)
62.4 (2.5)
137 (5.4)
51 (2)
156.5 (6.2)
70
72
