D Battery pack
q Attach the battery pack into the transceiver.
Battery pack
w Lock the battery pack with the latch.
Latch
CAUTION:
NEVER remove or attach the battery pack when the
transceiver is wet or soiled. This may result in water or
dust getting into the transceiver and battery pack, and
may result in them being damaged.
Be careful! The latch is tightly locked, so use caution
when releasing it. DO NOT use your nger nail. Use the
edge of a coin or screwdriver tip to carefully release it.
D Belt clip
Attach the belt clip to the transceiver.
Supplied screws
To Next Page
