!1 ATIS ICON (pp. 9, 23)
Appears when the channel group, in which ATIS func-
tion is activated, is selected or while programming an
ATIS code.
• For only the HOL and FRG versions.
!2 CALL CHANNEL ICON (p. 8)
Appears when the Call channel is selected.
!3 CHANNEL GROUP ICON (p. 9)
“USA” appears when U.S.A.*
1
; “INT” appears when
International; “CAN” appears when the Canadian*
2;
“ATIS” appears when ATIS*
3
channel group is selected.
*
1
Only USA, UK, EXP, CHN and AUS versions.
*
2
Only USA, EXP and CHN versions.
*
3
Only HOL version.
!
4 WEATHER CHANNEL/WEATHER ALERT ICONS* (p. 10)
• “ ” appears when the Weather channel group is
selected.
• “
” appears when the Weather alert function is
activated.
*Selectable on only the USA, EXP, and AUS versions.
!5 TRANSMIT POWER ICONS (p. 11)
• “LOW” appears when low power is selected.
• “MID” appears when mid power is selected.
• No indication appears when high power is selected.
!6 TRANSMIT ICON (p. 11)
Appears during transmit.
!7 BUSY ICON (pp. 11, 12)
Appears when a signal is received, or the squelch
opens.
