SPECIFICATIONS AND OPTIONS
10
■ Specications
All stated specications are subject to change without notice
or obligation.
IC-M85 (USA, Export):
D General
• Frequency coverage:
Marine TX 156.025 ~ 157.425 MHz
RX 156.050 ~ 163.275 MHz
LMR 136.000 ~ 174.000 MHz
• Mode:
Marine 16K0G3E
LMR 16K0F3E (Wide)/11K0F3E (Narrow)
• Channel spacing:
Marine ±25 kHz
LMR
±25 kHz (Wide), ±12.5 kHz (Narrow)
• Current drain (at 7.2 V DC): TX High (5 W) 1.5 A typical
Maximum audio 450 mA typical
• Frequency stability: ±5.0 ppm
• Operating temperature range:
Marine –20˚C ~ +60˚C, –4˚F ~ +140˚F
LMR –30˚C ~ +60˚C, –22˚F ~ +140˚F
• Dimensions (projections not included):
56 (W) × 92 (H) × 29 (D) mm,
2.2 (W) × 3.6 (H) × 1.1 (D) inches
• Weight (approximately): 215 g, 7.6 oz with BP-290
• Antenna impedance: 50 ˘ nominal
D Transmitter
• Output power:
Marine 5 W (Hi), 3 W (Mid), and 1 W (Low)
LMR (USA) 2 W (Hi), 1 W (Low)
LMR (Export/Chinese)
5 W (Hi), 3 W (Mid), and 1 W (Low)
• Modulation system :
Variable reactance frequency modulation
• Maximum frequency deviation:
Marine ±5 kHz
LMR ±5 kHz (Wide), ±2.5 kHz (Narrow)
• Audio harmonic distortion: Less than 10% (at 60% deviation)
• Spurious emissions: Less than –70 dBc typical
D Receiver
• Receive system: Double conversion superheterodyne
• Sensitivity (at 12 dB SINAD): 0.25 μV (typical)
• Squelch sensitivity (Threshold):
0.35 μV (typical)
• Intermodulation rejection ratio:
70 dB (typical)
• Sprious response rejection ratio:
70 dB (typical)
• Adjacent channel selectivity: 70 dB (typical)
55 dB (typical) (Narrow, LMR only)
• Ham and Noise ratio: 40 dB
34 dB (Narrow, LMR only)
• Audio output power: 0.7 W typical at 10% distortion into a
12 ˘ load
