PANEL DESCRIPTION
!8 TUNING STEP KEY [9 TS]
➥ Inputs digit ‘9’ for frequency input, memory
channel selection, etc.
➥ Push for 1 sec. to select the tuning step.
(p. 14)
!9 LOCK KEY [• LOCK]
➥ Inputs MHz digit for frequency input. (p. 15)
➥ Push for 1 sec. to toggle the lock function ON
and OFF. (p. 16)
•“ ” appears while the key lock function is in use.
@0 REWIND/ATTENUATOR KEY [
ΩΩΩΩ
ATT]
➥ Push to select the track for recorded audio.
(p. 64)
➥ Push and hold to rewind during playing the
recorded audio. (p. 64)
➥ Push for 1 sec. to turn the attenuator function
ON and OFF during normal operation. (p. 19)
@1 FAST FORWARD/RF GAIN KEY [
≈≈≈≈
RF GAIN]
➥ Push to select the track for recorded audio.
(p. 64)
➥ Push and hold to fast forward through the
recorded contents. (p. 64)
➥ Push for 1 sec. to enter the RF GAIN set
mode. Push to select the level after selecting
with [R-DIAL]. (p. 19)
@2 STOP/PLAY [■
≈≈
]
➥ Push to start the recorded audio. (p. 64)
➥ Push to stop the recording or playing audio.
(p. 64)
➥ Push for 1 sec. to enter the play speed set
mode. Push to select the item after selecting
with [R-DIAL]. (p. 65)
@3 RECORD KEY [ REC]
➥ Push to start recording audio. (p. 64)
➥ Push to pause recording audio. (p. 64)
➥ Push for 1 sec. to enter the record set mode.
Push to select the item after selecting with [R-
DIAL]. (p. 65)
