23
NOTE: Do not drop screws into bottom of dishwasher. If
side mounting you must predrill (¹⁄₈" drill bit) pilot holes in
cabinet to avoid splitting the wood before installing
screws.
Locate brackets on top of dishwasher and secure
dishwasher to countertop with two, #10 x ¹⁄₂" Phillips-head
screws (included). The dishwasher must be secured to
keep it from shifting when door is opened.
Secure dishwasher
3
Check that top of door does not contact screws,
brackets, or countertop. If it does, adjust leveling legs.
5
Check inner spacing
Open door and check that space between dishwasher
cabinet opening and tub is equal on both sides. If
spacing is not equal, loosen bracket screws secured
and shift tub. Tighten bracket screws.
Remove towel from dishwasher. Reinstall the lower dish
rack.
Remove towel and replace
lower dishwasher rack
7
If needed, see website for animated representation
of this step. Visit
www.ikea.com/anchoring under FAQ
tab.
plastic
button
6
Check side attachment
If securing with a side attachment, check that sides of door
do not rub against the screw heads. If they do, dishwasher
must be re-centered. When dishwasher is properly centered,
replace plastic buttons.
1
Reinstall access panels
Gr
Grounding
clip
Insulation
Insulation
(on some models)
Lower
panel
Access
panel
