hipot.com 12
Getting to Know Your Tester
1. Working with Memories
The SCI 290 series of testers are equipped with 5 memory programs numbered 1 through 5. Each memory can be
connected sequentially to the next consecutive memory. Only one test type can be selected for each memory location.
However, all 5 memory locations can be programmed and the parameters will be saved in each memory. The tests loaded
in each memory location can be executed one at a time or as a sequence.
2. Perform Test Screen
The Perform Test Screen displays the
following parameters:
Follow the setup procedures to set the desired parameters. The display will show the either the Hipot test settings or the
Insulation Resistance test settings:
*The underscore character may be displayed after the memory number, i.e. M1_. This indicates that another congured test will
execute after the displayed setup has completed.
Display* Description
AC Hipot test display
DC Hipot test display
Insulation Resistance test display
