Page 13INF6502WB/INF6502LC/INF7002WB/INF7002LC User Guide
Remote buttons
POWER
Power: Switches the power on or puts the monitor into Standby.
HOME
Home: Changes the active source back to the embedded PC.
INPUT
Input: Toggles the Input Source menu on and off, which allows the user to
change sources.
MENU
Menu: Turns the OSD menu on and off.
RESIZE
Resize: Switches between screen modes. Modes vary based on the source.
ON/OFF
PIP
PiP On/Off: Turns the PiP function on and off and changes the PiP
configuration between two active PiP sources. Options include corner and
side-by-side configurations (50%-resized, 25%-resized and 50%-fullscreen),
depending on source types.
INPUT
PIP
PiP Input: Switches the PiP window source. Note: The PiP window is not
visible when a secondary source has not been selected.
PIP
SWAP
PiP Swap: Switches the position of the main and secondary sources.
PIP
POSITION
PiP Position: Moves the PiP window position from corner to corner (upper left,
upper right, lower left, lower right).
PIP
AUDIO
PiP Audio: Turns the PiP audio mix on and off.
BRIGHTNESS
Brightness: Opens the Brightness OSD menu. Use the right and left arrow
buttons to adjust.
CONTRAST
Contrast: Opens the Contrast OSD menu. Use the right and left arrow buttons
to adjust.
BACK
Back: Returns the user to the previous menu.
OK
Left, Right, Up, Down Arrows and OK: Use these buttons to navigate through
and make changes to the Onscreen Menu features.
INFO
i
Info: Displays source information.
VOL UP
Vol up: Increases the audio volume.
VOL DOWN
Vol down: Decreases the audio volume.
MUTE
Mute: Switches the audio on or off.

InFocus INF6502WB Specifications

General

Panel life	- h
Pixel pitch	0.744 x 0.744 mm
Screen shape	Flat
Response time	6.5 ms
Backlight type	W-LED
Display diagonal	65 \
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display technology	LED
LED backlighting type	Direct-LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Contrast ratio (typical)	5000:1
Display number of colors	-
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	16
USB connector type	USB Type-A, USB Type-B
USB ports quantity	6
HDMI ports quantity	4
VGA (D-Sub) input ports	1
USB 2.0 Type-A ports quantity	5
Picture-in-Picture	No
Product color	Black
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB, VGA

Weight and Dimensions

Depth	83.1 mm
Width	1520.5 mm
Height	895 mm
Weight	53500 g
