InFocus INF6502WB User Manual

DRAFT
Page 14
Freeze: When enabled, freezes the image which is currently displayed.
Blank: Toggles between the source and a blank black screen.
Dimming: Adjusts brightness level.
USING THE KEYPAD
The keypad, located on the side of the monitor, has the following buttons:
^
^
^
^
Power button: Switches the power on or puts the monitor into Standby.
Input button: Turns the Source menu on allowing the user to change sources. Saves
changes/selections if the OSD menu is on.
^ button: Moves the highlight bar up when the OSD or Source menu is on.
v button: Moves the highlight bar down when the OSD or Source menu is on.
< button: When the OSD menu is on, this button decreases the value of selected OSD
items. When the OSD menu is off, this button decreases the audio volume.
> button: When the OSD menu is on, this button increases the value of selected OSD
items. When the OSD menu is off, this button increases the audio volume.
Menu button: Turns the OSD menu on and off.

InFocus INF6502WB Specifications

General

Panel life	- h
Pixel pitch	0.744 x 0.744 mm
Screen shape	Flat
Response time	6.5 ms
Backlight type	W-LED
Display diagonal	65 \
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display technology	LED
LED backlighting type	Direct-LED
Supported video modes	1080p
Touchscreen technology	Capacitive
Contrast ratio (typical)	5000:1
Display number of colors	-
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	16
USB connector type	USB Type-A, USB Type-B
USB ports quantity	6
HDMI ports quantity	4
VGA (D-Sub) input ports	1
USB 2.0 Type-A ports quantity	5
Picture-in-Picture	No
Product color	Black
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Number of built-in speakers	2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 40 °C
Cables included	AC, USB, VGA

Weight and Dimensions

Depth	83.1 mm
Width	1520.5 mm
Height	895 mm
Weight	53500 g
