DECALS OPERATION AND MAINTENANCE MANUAL
DECALS
ISO SYMBOLS
GRAPHIC FORM AND MEANING OF ISO SYMBOLS
Prohibition / Mandatory Information / Instructions Warning
WARNING: Electrical shock risk WARNING − Pressurised vessel. WARNING − Hot surface.
WARNING − Pressurised component or system. WARNING − Air/gas ow or Air discharge. Do not breathe the compressed air from this
machine.
Use fork lift truck from this side only. RESET Do not use fork lift truck from this side.
O (power).On (power).Emergency Stop.
Read the Operation and Maintenance manual
before operation or maintenance of this
machine is undertaken.
Do not operate the machine without the guard
being tted.
Lifting point.
ROTATION AIR DISCHARGE COOLANT FILTER
