User’s manual
General information 5
Chapter 1
General information
1.1 Manufacturer's details
Manufacturer: INIM ELECTRONICS S.R.L.
Production plant: Centobuchi, via Dei Lavoratori 10
Municipality: 63076, Monteprandone (AP), Italy
Tel.: +39 0735 705007
Fax: +39 0735 704912
E-mail: info@inim.biz
Web: www.inim.biz
The personnel authorized by the manufacturer to repair or replace the components of this system have authorization to
work only on devices marketed under the INIM Electronics brand.
1.2 About this manual
Manual code: DCMUINE0PREVIDIAC
Revision: 1.10
This manual describes the procedures for the configuration, commissioning and maintenance of the Previdia Compact
fire-detection system.
1.3 Operator qualifications - access levels
The control panel has 4 distinct access levels:
Level 1: Public level - this is the normal access level of the control panel and is the access level for building inhabitants
who are neither authorized to use the system nor instructed in its use.
At this level it is possible to display the information on the display and on the signalling LEDs, interact using the buttons
and touch screen to scroll through the information. Level 1 allows the following operations only:
• mute buzzer
• test signalling LEDs
• activate alarm signalling when an early-warning process is running
Level 2: Authorized users - this access level is for the system supervisors and is for authorized personnel who are
adequately instructed in the use of the system and its functions.
Access requires the use of a key or entry of a valid access code with sufficient access rights. In addition to the operations
described for level 1 it is also possible to carry out the following operations:
• mute alarm signalling devices
• rearm the control panel
• activate alarm signalling devices manually
• disable control panel elements
• place in test status one or more of the system elements
The system provides two additional sub-levels of authorized user:
- Superuser level, like the previous one, with the added possibility of replacing a loop device and registering control
panels to the Inim Cloud service account
- Maintenance operator level, same as the previous level with the added possibility of stopping the valve pulse for
those models that support extinction functions
Level 3: Programming - this access level is for specialized technical operators who carry out system configuration,
commissioning and maintenance.

INIM Electronics PREVIDIA-C-REP Specifications

General

Brand	INIM Electronics
Model	PREVIDIA-C-REP
Category	Control Panel
Language	English

Summary

PREVIDIA COMPACT User's Manual

Previdia Compact Product Overview

Describes the control panel's functions: fire alarm, extinguishant system, and communication.

Warranty and Legal Information

Product Warranty Details

Details the manufacturer's warranty, exclusions, and limitations for the product.

Limited Warranty and Copyright

Covers limitations on liability and intellectual property rights of the document.

General Information

Manufacturer and Manual Details

Provides contact information for INIM Electronics and details about the manual itself.

Operator Access Levels

Describes the four distinct access levels for system users and their permissions.

CE Mark and Standards

Details the CE mark and compliance with relevant European standards and directives.

Operative Statuses of the Previdia Compact System

User Interface Overview

Front Plate Models

Illustrates and describes the different user interfaces based on control panel models.

Repeater Interfaces

Shows and describes the user interfaces for two different repeater models.

Function Buttons and LEDs

Explains the purpose and status indication of function buttons and LEDs on the control panel.

Screen in Standby Status

Details the layout and function of the control panel screen when in standby mode.

Status Bar Icons and Functions

Describes the icons displayed on the status bar and their meanings for system status.

Inim Cloud Fire Service

Inim Cloud Home Page

Describes the elements and layout of the Inim Cloud Fire service home page.

Cloud Account Registration

Guides users through the process of registering a control panel to their Inim Cloud user account.

System Viewing and Monitoring

Viewing Active Events

Explains how to view active events on the system, categorized by icons and priority.

Events Log Visualization

Details how to access and interpret the system's event log, including event types and colours.

System Status Visualization

Describes how to view the status of control panels, zones, and their components.

System Operation and Management

System Programming Access

Explains how to access system configuration functions, requiring installer code.

Device Management

Details how to view and manage individual devices connected to the control panel.

Remote Communicator Management

Covers viewing and managing remote notification functions via telephone or 3G line.

Rapid Emergency Management Appendix
