Programming Manual
44 Programming the control panel
14.3.1 Parameters
FROM PANEL
<any key>, 8 Programming, <code>, 4 TIMER Programming,
1 Set Up timer,
or
<any key>,
8 <code> 4 1
Press keys and on the first line to
view the other timers.
Press keys and to scroll the
parameters list.
Press keys and on the other lines
to change the values.
14.4 Defining groups
FROM COMPUTER
Go to SmartLoop System, Control panel x, System Programming, Groups
This option will allow you to define up to 32 groups. The groups can be activated by related equations
or by zone signals which have been duly programmed.
The activation of a group can in turn activate or block zone signals which have been duly
programmed. Refer to paragraph 12.4 The zones.
Interval 1
Interval 2
Hour and minutes from start to end of the interval (time slot). If you do not wish to specify
an interval, leave “--”. If the two intervals are left as “--” the timer will be inactive.
Date Operational date of the timer. If you do not wish to specify the day, month or year, set “--”.
For example, to set the 3rd of every month of every year enter: day=3, month = “--”, year
= “--”. If you wish to create the setting using the day of the week (e.g. Monday), the day,
month and year fields must be left as “--”.
WeekDay Day of the week for weekly arrangements. Valid only when Day, month, year have no
setting.
If you select Holidays, the timer will activate during holiday periods.
If you select No holidays, the timer will not activate during holiday periods. Refer to
paragraph 13.4 Setting up holiday periods.
Actions on
Activation
Actions on De-
activation
ON timer activation/de-activation, the control panel will switch to Day/Night mode. This
operation can be managed by a timer or can be done manually at a control panel.
Timer tt
<Timer description>
STATUS : Disabled
Interval Number 1 :
