Chapter 2 Product Information
- 16 -
2.3 Technical Specications
Table 2-1 Technical Specications of the CS200
Item Description
Standard
functions
Max. frequency 150 Hz
Carrier frequency
0.5 to 16 kHz
The carrier frequency adjusts automatically depending on load characteristics.
Input frequency
resolution
Digital setting: 0.01 Hz
Analog setting: max. frequency x 0.025%
Control mode
Sensorless vector control (SVC)
Voltage/Frequency (V/F) control
Startup torque
V/F control: 0.5 Hz/150%
SVC: 0.5 Hz/200%
Speed range 1:100 (SVC)
Speed stability
accuracy
±0.5% (SVC)
Overload capacity
60 seconds for 150% of the rated current
3 seconds for 180% of the rated current
Torque boost
Fixed boost
Customized boost 0.1% to 30.0%
Ramp mode
Straight-line ramp
S-curve ramp
DC injection braking
DC injection braking frequency: min. frequency to rated frequency
Current level of DC injection braking: 0.0% to 120.0% of rated current
Auto voltage regulation
(AVR)
It can keep constant output voltage automatically when the line voltage
changes.
Overvoltage and
overcurrent stall control
The system limits the output current and voltage automatically during running
to prevent frequent or excessive tripping.
Fast current limit The system applies the fast limit function to avoid frequent overcurrent faults.
Torque limit and control
The system limits the torque automatically to prevent frequent overcurrent
tripping during running.
