Inovance IS300 Series User Manual

- 159 -
Chapter 7 Servo Pump Commissioning
Steps and Prototyping of servo pump
optional parts
7.1 Servo Pump Commissioning Process
Servo driver
commissioning
Set the relevant parameters correctly
Motor parameter tuning
*Motor commissioning, adjust parameters
of the speed and current loop
Oil pressure control mode setup
Motor parameter（F1）
Control parameter
（A3-00、F0－02）
Motor
commis
sioning
*AI zero drift automatic correction
*Function parameter setup
*Injection molding machine commissioning,
adjust pressure loop parameter
Servo
pump
applicati
on
Finish
Motor parameter tuning
（F1-16）
Motor response parameter
（F2）
Oil pressure control mode
（A3-00）
AI zero drift auto correction
（A3-20）
Flow and oil pressure
command（A3-01、02、03）
Pressure relief（A3-08）
Minimum flow（A3-09）
Minimum pressure（A3-10）
Oil pressure PID（A3）
Note：（1）Detailed instructions please refer to the following corresponding contents.
（2）Do not conduct the commissioning steps with *, it can also start the injection molding machine action.
7.2.1
7.2.1-1、7.2.1-2
7.2.1-3、7.2.1-4
7.2.1-5
7.2.1-6
7.2.2-1
7.2.2-3
7.2.2
7.2.2-4
7.2.2-5
7.2.2-6
7.2.2-7
