2.10.2 Selection of braking resistor Power
Theoretically, braking Power is consistent with braking Power.But in
consideration of the 70 percent derating,please refer to the formula
0.7*Pr=Pb*D, Pr refers to the resistor Power, D refers to braking
frequency(Which is the regeneration process accounting for the proportion of
the whole working process).For example, the braking frequency of elevator is
between 20% to 30%, the winding and unwinding is between 20% to 30%.The
centrifuge is between 50% to 60%, Occasional braking load is 5%. Injection
molding machine braking load is 10%.
Table 2-6Servo driver Bake Components Prototyping Table
Servo
Driver
model
Recommended
Power of
Brake Resistor
Recommended
Resistance
Value of Brake
Resistor
Braking
Unit
Remarks
IS300T005 300W ≥130Ω
IS300T010 400W ≥90Ω
IS300T015 500W ≥65Ω
IS300T020
800W ≥43Ω
IS300T030 1000W ≥32Ω
IS300T035 1300W ≥25Ω
IS300T040
1500W ≥22Ω
IS300T050 2500W ≥16Ω
Built-in as
standard
No special
specification
IS300T070
3.7 kW ≥16Ω
Externally
connected
MDBU-35-B
IS300T080
4.5 kW
≥16Ω Externally
connected
MDBU-35-B
IS300T100
5.5 kW
≥8Ω Externally
connected
MDBU-70-B
IS300T140
7.5 kW
≥8Ω Externally
connected
MDBU-70-B
IS300T170
4.5 kW×2
≥8Ω×2 Externally
connected
MDBU-70-B×2
IS300T210
5.5 kW×2
≥8Ω×2 Externally
connected
MDBU-70-B×2
