Intel® Server Board S1200SP Family Technical Product Specification
15
3 Functional Architecture
The architecture and design of the Intel
®
Server Board S1200SP is based on the Intel
®
C230 series chipset. The
chipset is designed for systems based on the Intel
®
Xeon
®
processor in an LGA 1151 Socket H4 package.
The Intel
®
Server Board S1200SPS uses Intel
®
C232 chipset. The Intel
®
Server Board S1200SPL and Intel® Server
Board S1200SPO use Intel
®
C236 chipset.
The Intel
®
Xeon
®
Processor E3-1200 V5 and V6 Processors are made up of multi-core processors based on the
14nm processor technology. The 6
th
Intel
®
Core
™
i3 Processors are made up of dual-core processors based on
the 14nm processor technology.
This chapter provides a high-level description of the functionality associated with each chipset component
and the architectural blocks that make up the server boards.
BMC Boot
Flash
SPI
Zoar
BMC
Pilot III
Springville
Ch A Ch B
DDR4 (Ch B)
XDP0
DMI Gen3 x 4
PCIe Gen3 x 1 P12
PCIe Gen3 x 1 P11
USB 2.0
4 DDR4
UDIMM
GbE
GbE
DDR4 (Ch A)
FLASH
DRAM
SERIAL A
Back
Panel
Back
Panel
Back
Panel
SPI
DDR4-2133 (POR)
SGPIO
Springville
USB
2
USB 3.0
(include 2.0 pair)
USB
1.1
USB
2.0
14
6
HDD
8
SATA 6G
Back
Panel
USB 3.0
LPC TPM Header
PCIe Gen3 x4 P1-P4
2
P13-16,17-20
P1-P2
Front Panel
USB 3.0
Header
SAS
Module
Silver Pass Block Diagram
CPLD
Phy
GbE
Mgmt LAN
Back
Panel
RGMII
Misc
VR s
VCC[0:2]
Vddq
Vtt
VCCio
VCCsa
VDDq
Vtt
Vpp
Slot 6
(x16 connector)
(x8 connectors)
Resister
Switch
Slot 5
Slot 4
(LC/SE SKU)
(x8 connectors)
PCIe Gen3 x 1 P10
P1 P5
P3-P4
2
P2,P4
USB
Back
Panel
USB 2.0
2
P10,P12
2
P9,P11
Skylake-S
SKT-H4
PCIe Gen3 x8 P0-P7
SKL PCH-H
PCH
PCIe Gen3 x8 P8-P15
IOM
(RO SKU)
Resistor
MUX
Note: Slot4 and IOM is exclusive
M.2 SATA SSD (2242
Form-Factor)
Note: A Separate
Cable Connection to
either 8 SATA Pin
required to support M.2
SATA SSD
RMM4 Lite
Front Panel
USB 2.0
Header
P6,P8
2
Internal
Type-A
P3
PCIe Gen3 x 1 P9
Note: NA for SE SKU.
Note: Work in Gen1 Mode
Note: Work in Gen1 Mode
Note: Work in Gen1 Mode
Note: Build-in SATADOM
Support on SATA P4
DP x1 Rear
Panel
VCCgt[0:3]
VCCopio
VCCEDRAM
VCCgtu
V1V8_EDRAM
Note: unslice,
OPIO, EDRAM,
P1V8_EDRAM
is reserved for
44e Support.
FLASH
DP to VGA
FLASH
MUX
Figure 14. Intel
®
Server Board S1200SP Functional Block Diagram
3.1 Processor Subsystem
The Intel
®
Server Board S1200SP supports the following processor:
• Intel
®
Xeon
®
processor E3-1200 V5 and V6 product family
• The 6
th
Generation Intel
®
Core
™
i3 processors
Note: The previous generation Intel
®
Xeon
®
processors are not supported on the Intel
®
server board described
in this document.
