Intel® Server Board SE7520JR2 Functional Architecture
Revision 1.0
C78844-002
39
Using the following algorithm, BIOS configures the memory controller of the MCH to run in
either dual channel mode or single channel mode:
(1) If 1 or more fully populated DIMM banks are detected, the memory controller is set to
dual channel mode. Otherwise, go to step (2)
(2) If DIMM 1A is present, set memory controller to single channel mode A. Otherwise,
go to step (3)
(3) If Channel 1B DIMM is present, set memory controller to single channel mode B.
Otherwise, generate a memory configuration error
DDR-266 & DDR-333 DIMM population rules are as follows:
(1) DIMM banks must be populated in order starting with the slots furthest from MCH
(2) Single rank DIMMs must be populated before dual rank DIMMs
(3) A maximum of four DIMMs can be populated when all four DIMMs are dual rank DDR-333
DIMMs.
DDR2 400 DIMM population rules are as follows:
(1) DIMMs banks must be populated in order starting with the slots furthest from MCH
(2) Dual rank DIMMs are populated before single rank DIMMs
(3) A maximum of four DIMMs can be populated when all four DIMMs are dual rank DDR2-400
DIMMs
The following tables show the supported memory configurations.
• s/r = single rank
• d/r = dual rank
• E = Empty
Table 3: Supported DDR-266 DIMM Populations
Bank 3 – DIMMs 3A, 3B Bank 2 – DIMMs 2A, 2B Bank 1 – DIMMs 1A, 1B
S/R S/R S/R
E S/R S/R
E E S/R
D/R D/R D/R
E D/R D/R
E E D/R
D/R S/R S/R
D/R D/R S/R
MCH
E D/R S/R
Table 4: Supported DDR-333 DIMM Populations
Bank 3 – DIMMs 3A, 3B Bank 2 – DIMMs 2A, 2B2 Bank 1 – DIMMs 1A, 1B
S/R S/R S/R
E S/R S/R
MCH
E E S/R
