Intel® Server Board SE7520JR2 System BIOS
Revision 1.0
C78844-002
95
Feature Options Help Text Description
DIMM 3A Installed
Not Installed
Disabled
Mirror
Spare
Informational display.
DIMM 3B Installed
Not Installed
Disabled
Mirror
Spare
Informational display.
Extended Memory Test 1 MB
1 KB
Every Location
Disabled
Settings for extended memory test
Memory Retest
Disabled
Enabled
If "Enabled", BIOS will activate and
retest all DIMMs on the next
system boot.
This option will automactically
reset to "Disabled" on the next
system boot.
Memory Remap Feature Disabled
Enabled
Enable: Allow remapping of
overlapped PCI memory above the
total physical memory.
Disable: Do not allow remapping of
memory.
Memory Mirroring / Sparing
Disabled
Spare
Mirror
Disabled provides the most
memory space. Sparing reserves
memory to replace failures.
Mirroring keeps a second copy of
memory contents.
Sparing or Mirroring is
grayed out if the installed
DIMM configuration does
not support it.
4.4.2.3 Boot Menu
Table 31: BIOS Setup, Boot Menu Selections
Feature Options Help Text Description
Boot Settings
Boot Settings Configuration N/A Configure settings during system boot. Selects submenu.
Boot Device Priority N/A Specifies the boot device priority sequence. Selects submenu.
Hard Disk Drives N/A Specifies the boot device priority sequence from
available hard drives.
Selects submenu.
Removable Drives N/A Specifies the boot device priority sequence from
available removable drives.
Selects submenu.
CD/DVD Drives N/A Specifies the boot device priority sequence from
available CD/DVD drives.
Selects submenu.
