6 / 36 P/N 146550999-1 • REV C • ISS 30APR12
Alarm memory
When SW1-5 is set to Remote on, alarms that occurred during
the night mode are stored in the detector memory. They are
indicated by flashing red LED when the unit switches to day
mode (walk test disabled). The memory is cleared when the
detector switches back to the night mode.
Note: Set SW1-6 to Off to prevent showing the alarm memory
on the LEDs. See “SW1-6: LEDs” on page 5.
LEDs and outputs
To enable LEDs functionality, set SW1-6 to On, otherwise
LEDs are disabled in any condition. See “SW1-6: LEDs” on
page 5 for more details.
Table 5: LEDs and outputs
Status Red
LED
Alarm
relay
Fault
relay
To reset
Start up
Closed Closed Automatically after
60 s
Low voltage
Open Open Apply correct voltage
PIR intruder alarm
Closed Closed
Microwave intruder
alarm
Closed Closed
Dual motion
intruder alarm
Open Closed Automatically after
3 s
Latched PIR
(memory)
Closed Closed Switch to the night
mode
Continuously on Normal blinking (1 Hz)
Specifications
Detector technology:
DD1012
DD1012PI
Dual
Dual, pet immune
Range 4, 6, 9, 12 m selectable via SW1-1
and SW1-2
Viewing angle 78 degrees
PIR optics 9 high-density mirror curtains
Microwave frequency 5.8 GHz
Max microwave output at 1 m 0.003 μW/cm²
Memory function Yes
Input power 9 to 15 V (12 V nominal)
Peak-to-peak ripple immunity 2 V (at 12 V)
Detector start-up time 60 s
Current consumption 5 to 16 mA (8 mA nom.)
Mounting height 1.8 to 3.0 m (5.90 to 9.84 ft.)
Target speed range 0.2 to 3.0 m/s (8 in./s to 10 ft./s)
Alarm (NC) / Tamper relay
characteristic
80 mA 30 V, Form A
Alarm time 3 s
Operating temperature −10 to +55°C (14 to 130°F)
Relative humidity 95% max., noncondensing
Weight 120 g
Dimensions (H x W x D) 126 × 63 × 50 mm
IP/IK rating IP30 IK04
Pry-off tamper Optional (ST400)
Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
Contact information
www.utcfireandsecurity.com or www.interlogix.com.
For customer support, see www.interlogix.com/customer-
supp
ort.
DA: Installationsvejledning
Beskrivelse
DD1012(-D) & DD1012PI er kombi detektorer. De omfatter den
patentbeskyttede PIR-spejloptikteknologi med den
patentbeskyttede Range Controlled Radar-teknologi.
DD1012PI er designet til at ignorere en given størrelse og
bygning af kæledyr. Kæledyr op til 18 kg (ca 35 cm høje) giver
normalt ikke problemer ved standardanvendelse, medmindre
de kan bevæge sig over 35 cm fra gulvet i detektorens
synsfelt.
Installationsvejledning
Se figur 1.
Detektoren er beregnet til vægophæng men kan også
monteres i loftet med et monteringsbeslag.
Følg denne vejledning til at fastlægge den bedste placering til
installation af detektoren.
• Monter detektoren så den forventede bevægelse ved et
indbrud er på tværs af detektionsmønstret (se figur 3).
• Monter detektoren på en stabil overflade i en højde på
1,8 m — 3,0 m fra gulvet.
• Monter ikke detektoren på en afstand af 0,5 m fra
metalgenstande eller 1,5 m fra lysstofarmaturer.
• Placer ikke en genstand foran detektoren, som kan
forhindre en direkte synslinje.
• Placer detektorerne mindst 6 m fra hinanden og juster
afstanden på enheden, således at man undgår interferens
ved montering af detektorerne rettet mod hinanden.
Detektorteknologien beskytter effektivt mod falske alarmer.
Undgå imidlertid mulige årsager til ustabilitet, f.eks.:
PIR-fare:
• Direkte sollys på detektoren
• Varmekilder inden for detektorens synsfelt
To Next Page
