Intermec PF8T User Manual

Chapter 3 — Troubleshooting and Maintaining the Printer
56 PF8d and PF8t Desktop Printer User’s Guide
Adjusting the Printer
Keeping the printhead properly balanced is crucial for obtaining high
quality printouts. You can adjust the:
• printhead pressure.
• printhead alignment.
• printhead sensor mode (dotline).
Adjusting the Thermal Printhead Pressure (PF8t Only)
When you print with different label materials or use different types of
ribbons on the PF8t, print quality may be affected due to differences
in the material. If this happens, adjust the thermal printhead pressure
appropriately for the type of material you are using.
To adjust thermal printhead pressure
1 Turn off power to the printer.
2 Press the cover open buttons on both sides, and open the cover.
3 Use a slotted screwdriver to turn the screws clockwise to increase
printhead pressure or counterclockwise to decrease printhead
pressure.
Adjustment
screws
(2 places)

Intermec PF8T Specifications

General

Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	118 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.65 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V

Weight and Dimensions

Weight	2000 g
