Intermec PF8T User Manual

Chapter 3 — Troubleshooting and Maintaining the Printer
PF8d and PF8t Desktop Printer User’s Guide 57
Adjusting the Printhead Alignment
You can improve the print quality by adjusting the alignment between
the printhead and the platen roller.
To adjust the printhead alignment
• Turn the adjustment screw counterclockwise or clockwise to
adjust the contact between the printhead and platen roller.
Adjusting the Label Taken Sensor
You can enable the built-in label taken sensor to pause printing until
a printed label is removed from the printer output slot. The printer
continues printing when the label taken sensor no longer detects a
label.
When you are using the protocol, note the following:
• You need to install the optional self-strip module to use the label
taken sensor.
• You need to manually enable the label taken sensor using the
switch next to the sensor before you can enable or disable it using
commands.
Adjustment
screw

Intermec PF8T Specifications

General

Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	118 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.65 \
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V

Weight and Dimensions

Weight	2000 g
