41
8.2.3.1 Removing the batteries
Requirements:
• Wrench 11 mm
• Remove the seat.
• Remove the battery and motor compartment cover.
• Disconnect the main cable harness.
• Open the belts that hold the batteries in place (1).
• Loosen battery clamp of the blue cable at the negative pole
of the battery with the wrench and remove cable.
• Loosen the battery clamp of the red cable at the positive
pole of the battery with the wrench and remove cable.
• Repeat procedure on the other side.
NOTE
Fitting of new batteries is done in reverse order.
