10.1.1 Repairing a flat tyre (pneumatic tyres type 260 x 85)
10.1.1.1 Removing a rear wheel
Requirements:
• Spanner 19 mm
• Rubber hammer
• Jack the vehicle up and place a block of wood underneath it
to prop it up.
• Remove the nut that secures the wheel (1) using the 19 mm
spanner.
• Remove the wheel, using the rubber hammer to coax it off of
the axle by gently hitting it on the rear side.
Having trouble removing the wheel?
You might need to use a special tool. Please ask your authorized Invacare® Dealer for
assistance.
Re-assembly
Re-assembly is done in reverse order. Make sure that the wheel is put back on the same side it
was on, and that it runs in the same direction it did before it was removed.
