Goodrive300-01A series VFD for air compressor Function code description
-28-
5 Function code description
“○” indicates the parameter value can be modified during stop and running;
“◎” indicates the parameter value cannot be modified when the VFD is running;
“●” indicates the parameter value is the actually detected value which cannot be modified.
(The modification attribute of each parameter has been restricted automatically by the VFD to avoid
inadvertent modification)
5.1 Function codes
Function
code
Name
Parameter description
Default
value
Modify
P00.00
Speed control mode
0: SVC mode 0 (applicable to AM,SM)
1: SVC mode 1(applicable to AM)
2: V/F control
3: VC mode (applicable to SM)
Note:
AM-Asynchronous Motor;
SM-Synchronous Motor;
If vector mode is adopted, it is a must to carry
out motor parameter autotuning on the VFD
first.
0
◎
P00.01
Running command
channel
0: Keypad (LED off)
1: Terminal (LED blinks)
2: Communication (LED on)
0
○
P00.02
Communication
running command
channel
0: Modbus communication
1–3: Reserved
0
○
P00.03
Max. output frequency
P00.04–600.00Hz (400.00Hz)
50.00Hz
◎
P00.04
Upper limit of running
frequency
P00.05–P00.03 (max. frequency)
50.00Hz
◎
P00.05
Lower limit of running
frequency
0.00Hz–P00.04 (upper limit of running
frequency)
0.00Hz
◎
P00.06
A frequency command
selection
Note: A frequency and B frequency cannot be
set to the same frequency reference mode.
You can set the frequency source through
P00.09.
0: Set via keypad digits
1: Set via analog P1-
2: Reserved
3: Set via analog P2-
4: Reserved
5: Reserved
0
○
P00.07
B frequency command
selection
2
○
