INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Function code description
-62-
Function
code
Name
Parameter description
Default
value
Modify
VFD, if the fault persists after the VFD
continues running at alternative frequency of
P21.10 in the time set by P21.11, the VFD will
coast to stop; if the fault no longer occurs
during P21.11, the VFD restores to normal
mode.
P21.13
Display current of A
phase of the fan
0.0–40.0A
0.0A
●
P21.14
Display current of B
phase of the fan
0.0–40.0A
0.0A
●
P21.15
Display current of C
phase of the fan
0.0–40.0A
0.0A
●
P21.20
Fan state
0X0000–0XFFFF
Bit0: when it is 1, it means power-frequency
fan is started
0x0000
●
5.2 Control logic of the air compressor
(1) The following figure shows the control logic of the air compressor.
