Goodrive300-01A series VFD for air compressor Appendix A
-74-
A.3 Wall installation dimension
H1
H2
W1
W2
D2
Ø
D1
Figure A-1 7.5kW–37kW wall installation diagram
H1
H2
W2
W1
D1
D2
W3
Figure A-2 45kW–55kW wall installation diagram
