Quick Reference
Flag Function
Description
Flag Function Description
CC The power supply is
in a state of con-
stant current output.
Addr When received command
successfully, the flag will dis-
play 3 seconds.
* The keyboard lock
is turned on.
Rmt Indicates that the instrument
is working in remote control
mode.
CR None Error Error occur
Shift Using composite
function key
Prot The instrument enters the
protection state.
SRQ Indicates that the
internal status re-
quest event occurs.
Trig The instrument is in a state
of waiting for a trigger.
CW The power supply is
in a state of con-
stant power output.
- -
1.7 Configuration Menu Function
This section gives an overview of the configuration menu of the IT6000C series
power supply.
The procedures to operate the configuration menu are as follows.
1. Press the composite keys [Shift]+[V-set] (Config) on the front panel to enter
the configuration menu.
The VFD shows configuration menu items and each menu item is marked
with a number. The user can use up and down keys or knob to scroll pages
to view the other menu items.
2. Press [Enter] to select the desired menu item.
Enter the parameter setting interface of this menu item.
3. After finishing the menu setting, press [Enter] key to save the setting.
Press [Esc] key to return to the previous menu level.
Copyright © Itech Electronic Co., Ltd.
9
