Power Supply Function

4.6.3 Built-in Waveform Function

The IT6000C series power supply supports built-in waveforms for user to exe-

cute the test directly. The protocols/standards involved in the built-in waveforms

include the following:

• DIN40839

• ISO16750-2

• ISO21848

• SAEJ1113–11

• LV123

• LV124

The following is a general overview of this function menu, and the detailed pa-

rameters of the waveform corresponding to each protocol/standard can be

found in the corresponding chapter.

If there is a waveform parameter related to setting the voltage val-

ue, when the upper limit of the voltage setting defined in the reg-

ulation exceeds the rated voltage of the instrument, the rated

voltage of the instrument is set as the upper limit. Otherwise, the

output waveform may be distorted.

Road-

Vehicles

Vehicle waveform function menu

DIN40839

Evaluation of automotive starting

waveform

ISO16750-2

Simulate the waveform to verify the

anti-interference performance of the au-

tomotive electronics’ products.

ISO21848 42V Road vehicles — Electrical and

electronic equipment for a supply volt-

age of 42 V — Electrical loads

SAEJ1113-11 SAEJ1113-11 Waveform protocol

LV123 LV123 Waveform protocol

LV124 LV124 Waveform protocol
