JACOBSEN AR3
SAFETY, OPERATORS & MAINTENANCE MANUAL
4 SPECIFICATIONS
4.1 ENGINE SPECIFICATION
TYPE: Kubota 24.5KW (32.8HP) @
3000 RPM, 3 cylinder (in line)
Turbo charged Diesel engine, 4
stroke, water cooled, 1123cc
(68.53cu.in) with 12V 1KW
electric start, 12V 30Amp
Alternator
Model: D1105-T-E3B-RNUK-3
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 25 RPM
Oil Sump Capacity: 5.1 litres (1.35 US gals)
Fuel: No. 2-D Diesel fuel (ASTM
D975)
4.2 MACHINE SPECIFICATION
Frame construction: Heavy duty formed steel
chassis with box section frame
rails.
Cutting unit drive: Fixed displacement hydraulic
motors.
Transmission: 3-wheel drive. Direct
coupled variable displacement
pump to direct coupled 200cc/
rev front, 400cc/rev rear wheel
motor.
Speeds:
Cutting: 0 - 9.5 km/h (0 - 5.9 mph)
FORWARD
Transport: 0 - 14 km/h (0 - 8.5 mph)
FORWARD
Reverse: 0 - 6 km/h (0 -3.7 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Ground pressure: 1 kg/cm
2
(14p.s.i.)
Brakes: Hydrostatic braking with
hydraulic parking brakes on
front wheels.
Fuel Tank
Capacity: 45.4 litres (12 US galls)
Hydraulic Tank
Capacity: 25 litres (6.6 US galls)
Battery: Exide 093 (SAE 500)
4.3 DIMENSIONS
SERUSSERPERYT
tcudorP
leehWtnorF leehWraeR
eziSeryTepyTeryTerusserPeryTeziSeryTepyTeryTerusserPeryT
3RA01-00.21x02
rp4carTfruTi
sp02-41rab73.1-00.1
8-00.01x02
rp4carTfruTisp22-41rab15.1-00.1
AtucfohtdiWmc381sehcni27
BhtdiwtropsnarTmc002sehcni97
CSPORtuohtiwthgiehllarevOmc431sehcni7.25
Ddda,SPORhtiwthgieh
llarevOmc84sehcni91
EhtgneLllarevOmc213sehcni321
FkcarTleehWmc231sehcni25
GesaBleehWmc151sehcni57.95
HleseiD-enihcaMf
othgieWgk068bl6981
J)hcae(tinUgnittuCfothgieWgk19bl102
