CONTROLS 4
en-34
4.2.6.37 WARNING CONTROLLER I/O FAULT _______________________________________
When this screen is shown, there is a controller I/O fault.
Go to I/O Diagnostics for solenoid identification. See Section 4.2.6.19
Glow Relay Fault (J5-8)
Start Relay Fault (J1-6)
Fuel Hold Fault (J2-6)
Fuel Pull Fault (J6-1)
Park Brake Solenoid Fault (J2-5)
Lower Solenoid Fault (J2-1)
Lift Solenoid Fault (J2-3)
Mow Solenoid Fault (J5-2)
Backlap Solenoid Fault (J6-3)
Fan Output Fault (J2-4)
4WD Relay Fault (J5-7)
4.3 THROTTLE LEVER_________________________________________________________
The throttle lever controls the engine speed. Always operate the mower at
full throttle during normal operation.
Push the throttle lever toward the front of the mower to increase engine
speed.
Pull the throttle lever toward the rear of the mower to decrease engine
speed.
4.4 ARMREST ADJUSTER______________________________________________________
The armrest adjuster is found on the right side under the Armrest.
• Lift up on the adjuster lever and slide the armrest in the forward or
rearward direction. Release the adjuster lever to set the adjustment.
See Section 7.4 for armrest height and angle adjustments.
CAUTION
To prevent injury or property damage, do not adjust the armrest position while
the mower is in motion.
!
Lowe
r
Solenoid Fault (J2-1)
1/1
!
Lift Solenoid F
a
ult (J2-3)
1/
1
!
F
an
Output Fault (J2-4)
1/1
!
Park Brake Solenoid Fault
(J2-
5
)
1/1
!
Fue
l Hold F
au
lt (J2
-
6
)
1/1
!
Mow S
o
lenoid Fault (J5
-
2
)
1/
1
!
Fue
l Pull Fault (J6-1)
1/
1
!
Backlap Sole
n
oid Fault
(J6
-
3
)
1/1
!
Glow Relay F
au
lt
1/1
!
Start
Relay F
a
ult
1/1
