5 OPERATION
en-45
5.11 TO REMOVE A BLOCKAGE FROM CUTTING UNITS _____________________________
1. Stop and lift the cutter units before you move the machine to level ground.
2. Turn off the engine and remove the ignition key.
3. Wear the personal protective equipment that is applicable for this work, for example eye protection, gloves and
correct footwear. Use Bat (4184540), to remove the blockage.
4. Check the reel blades and bedknife for damage and replace if necessary.
5. Start the engine and run the cutter units to check for correct operation.
6.1 SLINGING AND JACKING THE MACHINE __________________________________
Slinging
When slinging the machine a set of four damage free wheel clamps must be used, similar
to the one shown, in conjunction with a certified lifting frame.
Jacking points
There are jack points indicated on the machine, one (3WD Option) or two (4WD Option) on the rear
axle and two on the front axle. This decal indicates the correct lift points.
WARNING
To reduce the risk of injury and infection from foreign objects always use the Bat (4184540) and heavy
duty leather gloves to remove a blockage from cutting unit.
