12 SPECIFICATIONS
en-89
12.6 NOISE ___________________________________________________________________
When the machine was tested for sound pressure (Operator Ear).
The Machinery Safety Directive 2006/42/EC
And
Exposure Of Workers To The Risks Arising From Physical Agents (Noise) Directive 2003/10/EC
By compliance to:
The Lawnmower Standard BS EN ISO 5395:2013
And
Sound Pressure Standard EN ISO 3746: 2010
ROPS machine: Measured Sound Pressure TBD dB(A) ± 0.6 LWA
When the machine was tested for sound power (Noise in the Environment).
The Machinery Safety Directive 2006/42/EC
And
Noise Emission In The Environment By Equipment For Use Outdoors
Directive 2000/14/EC
By compliance to:
Sound Power Standard EN ISO 3744:2010
Measured Sound Power 102 dB(A) ± 0.6 LWA
12.7 SLOPES _________________________________________________________________
DO NOT USE ON SLOPES GREATER THAN 21°. The slope was calculated using static stability measurements
according to the requirements of BS EN ISO 5395:2013
12.8 CUTTING PERFORMANCE __________________________________________________
208 cm (82 in.) width of cut:
1.82 hectares/hr. At 9.66 kph.
4.5 acres / at 6 mph
(10% allowance is included for normal overlaps and turning at the end of each cut).
12.9 CUTTER DECK SPECIFICATION _____________________________________________
Product
(2 LH Reels and 3 RH Reels
Required)
62298 (LH) / 62859 (RH) Reel Cutting Unit 62299 (LH) / 62860 (RH) Reel Cutting Unit
Number of Reel Blades 8 11
Reel Cutting Width 45.7 cm (18 inch)
Height of Cut 7.6 mm - 18 mm (0.30 inch - 0.70 inch)
Height of Cut Adjustment Lift or lower front roller with adjustment knobs on the ends of reel.
Transmission By Hydraulic motor to drive side of reel.
To Next Page
