98
26-3 Performing communication by using RS-232C
[ Setting procedure ]
It is possible to send and receive the data, by using RS-232C cable, with the personal computer or
the like. For the cable to be connected, connect reverse type 9-pin (female) to the operation panel
side
If the contact part becomes dirty, failure of contact will be caused. Do not touch by hand,
and control so that dust, oil, or other foreign material does not adhere to it. In addition, the
inside element is damaged by static electricity or the like. So, be very careful when handling.
* When the lower part of the cover located on the side of the operation panel is opened, there is
the connector of 9-pin for RS-232C. Connect the cable there. When the screw for locking is
attached to the connector, tighten the screw to prevent it from falling.
To Next Page
