– 27 –
(3) Function setting list
No. Item Description Setting range
1 Soft start The number of stitches to be sewn at a low speed when the soft-start 0 to 9 34
function function is used at the start of sewing. (Stitches)
0 : Soft-start function is not operative.
2 Material end Material end sensor function (used in case of without panel). 0/1 34
sensor 0 : Material end detection function is not operative
function 1 : After detecting material end, the specified number of stitches (No. 4) will
be sewn, and the sewing machine will stop.
3 Thread trimming Thread trimming function by material end sensor (used in case of without panel). 0/1 34
function by 0 : Automatic thread trimming function after detection of material end is not
material end operative.
sensor 1 : After detecting material end, the specified number of stitches (No. 4) will
be sewn, and the sewing machine will stop and perform automatic
thread trimming.
4 Number of Number of stitches for material end sensor (used in case of without panel). 0 to 19 34
stitches for Number of stitches from detection of material end to stop of the sewing (Stitches)
material end machine.
sensor
5 Flicker reducing Flicker reducing function (If the hand lamp flickers). 0 to 8 34
function 0 : Flicker reducing function is not operative.
1 : Less effective . 8 : Highly effective
6 Bobbin thread Bobbin thread counting function 0/1 34
counting 0 : Bobbin thread counting function is not operative.
function 1 : Bobbin thread counting function is operative.
7 Unit of bobbin Unit of bobbin thread counting down 0 to 2
thread counting 0 : Count/10 stitches
down 1 : Count/15 stitches
2 : Count/20 stitches
8 Number of Sewing speed of reverse feed stitching 180 to 3000
rotation of (r.p.m)
reverse feed
stitching
9 Thread Thread trimming prohibiting function (used in case of without panel). 0/1 34
trimming 0 :Thread trimming prohibiting function is not operative.
prohibiting 1 : Thread trimming is prohibited.
function (Output of solenoid is prohibited. : Thread trimmer and wiper)
10 Setting of Position of needle bar is specified when the sewing machine stops. 0/1 34
needle bar 0 : Predetermined lowest position
stop position 1 : Predetermined highest position
when the sewing
machine stops.
11 Click sound of Click sound of key switch mounted on PSC is specified. 0/1 34
key switch 0 : Click is not operative.
mounted on 1 : Click is operative.
PSC
12 Optinal switch Switching of function of optional switch. 0 to 8 35
function 0 : No function
selection 1 : Needle up/down compensating stitching
2 : Back compensating stitching
3 : Function of canceling once reverse feed stitching at the end of sewing
4 : Thread trimming function
5 : Presser foot lifting function
6 : One stitch compensating stitching
7 : Function of simultaneously canceling reverse feed stitching at the start
and end of sewing
8 : Neutral presser lifting changeover function
13 Function of Function of prohibiting start of the sewing machine by bobbin thread counting 0 to 2 43
prohibiting 0 : When counting is out (-1 or less) Function of prohibiting start of the
start of the sewing machine is not operative.
sewing 1 : When counting is out (-1 or less) Function of prohibiting start of the
machine by sewing machine is operative.
bobbin thread 2 : When counting is out (-1 or less) Function of forcibly prohibiting start of
counter the sewing machine is operative.
14
Sewing Counting function of sewing (number of completion of process)
0/1
35
counter 0 : Sewing counter function is not operative.
1 : Sewing counter function is operative.
15
Number of times Number of times of detection of run-out of bobbin thread remaining amount
0 to 19
of detection of 0 : Function of bobbin thread remaining amount is not operative.
run-out of 1 to 19 : Number of times during which the signal is not made even if run-out
bobbin thread of bobbin thread remaining amount is detected.
remaining
amount
1
0
2
0
3
0
4
5
5
0
6
1
7
0
8
1900
9
0
10
0
11
1
12
0
13
0
14
0
15
1
Indication of Ref.
function setting page
To Next Page
