Table 65: 2-Port Serial PIM Cables and Connectors (continued)

Pinouts

End-to-End

ConductorsConnector HardwareConnectorName

Table 69 on page 229254-40 threaded jacknutsDC-37 (DB-37) femaleRS-422/449 (EIA-449)

DCE

Table 70 on page 230234-40 threaded

jackscrews

DB-25 maleEIA-530A DTE

Table 71 on page 231224-40 threaded jacknutsDB-25 femaleEIA-530A DCE

Table 72 on page 23218Standard (Normally

included with M/34

connector shell)

M/34 maleV.35 DTE

Table 73 on page 23318Standard (Normally

included with M/34

connector shell)

M/34 femaleV.35 DCE

Table 74 on page 23313M3 threaded jackscrewsDB-15 maleX.21 DTE

Table 75 on page 23413M3 threaded jacknutsDB-15 femaleX.21 DCE

RS-232 DTE Cable Pinout

Table 66: RS-232 DTE Cable Pinout

DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin

Frame Ground–115

Transmit Data–260

Receive Data–31

Request to Send–448

Clear to Send–537

Data Set Ready–69

Signal Ground–757

Data Carrier Detect–813

Transmit Clock–1556

Receive Clock–175

Local Loopback–1841

Data Terminal Ready–2033

226 ■ Serial PIM Cable Specifications

J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
