Table 79: RJ-45 Chassis Console Connector Pinout
DescriptionSignalPin
Request to SendRTS Output1
Data Terminal ReadyDTR Output2
Transmit DataTxD Output3
Chassis GroundGND4
Chassis GroundGND5
Receive DataRxD Input6
Data Set ReadyDSR Input7
Clear to SendCTS Input8
Table 80 on page 237 describes the DB-9 connector pinouts.
Table 80: DB-9 Console Connector Pinout
DescriptionDirectionSignalPin
Carrier Detect<–DCD1
Receive Data<–RxD2
Transmit Data–>TxD3
Data Terminal Ready–>DTR4
Signal Ground—Ground5
Data Set Ready<–DSR6
Request To Send–>RTS7
Clear To Send<–CTS8
Ring Indicator<–RING9
E1 and T1 RJ-48 Cable Pinouts
The E1 and T1 PIMs use an RJ-48 cable, which is not supplied with the PIM.
CAUTION: To maintain agency approvals, use only a properly constructed, shielded
cable.
E1 and T1 RJ-48 Cable Pinouts ■ 237
Chapter 13: Network Cable Specifications and Connector Pinouts
