5-18
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
L6208 NQLZ011-221X COIL 220µH
L6701 NQLZ010-100X COIL 10µH
X1001 NAX0474-001X C OSCILLATOR
X1002 NAX0325-001X CRYSTAL RESONATOR
X1401 NAX0204-001X CRYSTAL RESONATOR
X3002 NAX0480-001X CRYSTAL RESONATOR
X4301 NAX0356-001X CXO
WR1 WJT0065-001A E-CARD WIRE,CN102-JACK CN502
WR2 WJJ0268-001A E-SI C WIRE C-C,CN104-REAR CN552
CN101 QGF0508F1-40X FPC CONNECTOR
CN102 QGF0505F2-24X FPC CONNECTOR
CN103 QGF0503C1-12V FFC/FPC CONNECTOR
CN104 QGA1002C1-06X CONNECTOR
CN105 QGB0801K2-30X CONNECTOR
CN106 QGA1201C2-07X CONNECTOR
CN107 QGF0503C1-20X FFC/FPC CONNECTOR
CN108 QGF0512C1-24X FPC CONNECTOR
CN109 QGF0507F4-15X FFC/FPC CONNECTOR
CN110 QGF0505F1-08X FPC CONNECTOR
CN111 QGB0501L1-A0X CONNECTOR
CN112 QGF0505F2-18X FPC CONNECTOR
CN113 QGF0508F1-33X FPC CONNECTOR
! F6101 NMFZ007-2R0X-K FUSE T2.0A,50V
OT1 LY43491-001A SHEET(MAIN)
OT2 LY43549-001A SHEET(MECHA)
SD1 LY32080-001A SHIELD CASE
******************************
MONITOR BOARD ASSEMBLY <02>
PW YB10360PG-02 MONITOR BOARD ASSY
IC7101 TC7SH32FU IC(DIGITAL)
IC7601 AN2540FHQ IC
IC7602 BA4558F IC
IC7603 AT25040N-10SC-X IC
or 25LC040-I/SN-X IC
IC7604 SN74LV08APW IC
Q7101 2SA1774/QR/-X TRANSISTOR
Q7102 2SC4617/QR/-X TRANSISTOR
Q7601 2SC4617/QR/-X TRANSISTOR
or 2SC4738/YG/-X TRANSISTOR
or 2SD2216J/QR/-X TRANSISTOR
Q7602 2SA1774/QR/-X TRANSISTOR
or 2SA1832/YG/-X TRANSISTOR
Q7603 2SC4617/QR/-X TRANSISTOR
or 2SC4738/YG/-X TRANSISTOR
or 2SD2216J/QR/-X TRANSISTOR
Q7604 2SA1774/QR/-X TRANSISTOR
or 2SA1832/YG/-X TRANSISTOR
Q7608 DTC144EE DIGI TRANSISTOR
or RN1104 DIGI TRANSISTOR
or UN9213J DIGI TRANSISTOR
Q7609 DTC144EE DIGI TRANSISTOR
or UN9213J DIGI TRANSISTOR
or RN1104 DIGI TRANSISTOR
Q7610 DTA144EE DIGI TRANSISTOR
or RN2104 DIGI TRANSISTOR
or UN9113J DIGI TRANSISTOR
D1 SML-110MT-X LE DIODE
D11 RSA6.1J4-W DIODE
D7601 FC806 SB DIODE
D7602 UDZS6.8B ZENER DIODE
R1 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R2 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W
R5 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R6 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R7 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R8 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W
R9 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R10 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R18 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R19 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R21 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R22 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R23 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R7110 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W
R7111 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7113 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7114 NRSA63J-271X MG RESISTOR 270Ø,1/16W
R7116 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R7601 NRVA63D-622X CMF RESISTOR 6.2kØ,1/16W
R7602 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R7603 NRSA63J-683X MG RESISTOR 68kØ,1/16W
R7605 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7606 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7608 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R7609 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7610 NRVA63D-433X CMF RESISTOR 43kØ,1/16W
R7611 NRVA63D-821X CMF RESISTOR 820Ø,1/16W
R7612 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7613 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7614 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7615 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7616 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7617 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R7618 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R7621 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7630 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7631 NRSA63J-335X MG RESISTOR 3.3MØ,1/16W
R7633 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R7636 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R7637 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R7638 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R7650 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7652 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
C1 NCB31EK-103X CAPACITOR 0.01µF,25V
C11 NBE20JM-106X T CAPACITOR 10µF,6.3V
C7101 NDC31HJ-221X CAPACITOR 220pF,50V
C7102 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7601 NCB21CK-105X CAPACITOR 1µF,16V
C7602 NCB31EK-103X CAPACITOR 0.01µF,25V
C7603 NCB11CK-225X CAPACITOR 2.2µF,16V
C7604 NCB11CK-225X CAPACITOR 2.2µF,16V
C7605 NCB11CK-225X CAPACITOR 2.2µF,16V
C7606 NCB31CK-104X CAPACITOR 0.1µF,16V
C7607 NCB41CK-106X CAPACITOR 10µF,16V
C7608 NCB31EK-103X CAPACITOR 0.01µF,25V
C7609 NCB31CK-104X CAPACITOR 0.1µF,16V
C7610 NCB11CK-225X CAPACITOR 2.2µF,16V
C7611 NCB11CK-225X CAPACITOR 2.2µF,16V
