# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C7612 NCB11CK-225X CAPACITOR 2.2µF,16V
C7613 NCB11CK-225X CAPACITOR 2.2µF,16V
C7614 NCB31HK-152X CAPACITOR 0.0015µF,50V
C7615 NCB31EK-103X CAPACITOR 0.01µF,25V
C7616 NCB31EK-103X CAPACITOR 0.01µF,25V
C7617 NCB31EK-103X CAPACITOR 0.01µF,25V
C7618 NCB10JK-106X CAPACITOR 10µF,6.3V
C7619 NCB10JK-106X CAPACITOR 10µF,6.3V
C7620 NCB31EK-103X CAPACITOR 0.01µF,25V
C7621 NCB21CK-105X CAPACITOR 1µF,16V
C7622 NCB21CK-105X CAPACITOR 1µF,16V
C7623 NBE21AM-106X T CAPACITOR 10µF,10V
C7624 NCB31EK-103X CAPACITOR 0.01µF,25V
C7626 NCB31CK-104X CAPACITOR 0.1µF,16V
C7627 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7628 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7629 NBP21CM-335X T CAPACITOR 3.3µF,16V
C7630 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7631 NCB31EK-103X CAPACITOR 0.01µF,25V
C7632 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7633 NCB31EK-103X CAPACITOR 0.01µF,25V
C7634 NCB11CK-225X CAPACITOR 2.2µF,16V
C7635 NCB31EK-103X CAPACITOR 0.01µF,25V
C7637 NCB31EK-103X CAPACITOR 0.01µF,25V
C7640 NCB31EK-103X CAPACITOR 0.01µF,25V
C7642 NCF31CZ-104X CAPACITOR 0.1µF,16V
L10 NQR0129-002X FERRITE BEAD
L7601 NQL365K-100X COIL 10µH
L7602 NQL365K-470X COIL 47µH
L7603 NQL365K-100X COIL 10µH
L7604 NQL365K-100X COIL 10µH
L7605 NQL365K-100X COIL 10µH
L7607 NQL365K-100X COIL 10µH
SW1 NSW0092-001X SLIDE SWITCH,VIDEO LIGHT
SW2 NSW0008-001X TACT SWITCH,STOP/BACKLIGHT
SW3 NSW0008-001X TACT SWITCH,REW/NIGHT
SW4 NSW0008-001X TACT SWITCH,FF
SW5 NSW0008-001X TACT SWITCH,PLAY/PAUSE
SW6 NSW0099-001X SLIDE SWITCH,VIDEO/MEMORY
SW7 NSW0160-001X TACT SWITCH,INFO
SW8 NSW0160-001X TACT SWITCH,INDEX
SW9 NSW0160-001X TACT SWITCH,E-MAIL
SW10 NSW0160-001X TACT SWITCH,SELECT
SW7601 QSW0451-001 PUSH SWITCH,MONITOR OPEN
J7601 QND0087-001 S JACK
! BT1 QAB0025-001 LI BATTERY
CN761 QGF0508F1-40X FPC CONNECTOR
CN762 QGF0508F1-10X FPC CONNECTOR
CN763 QGF0507F3-20X FFC/FPC CONNECTOR
CN764 QGF0508F1-33X FPC CONNECTOR
CN765 QGA1201F2-02X CONNECTOR
CN766 NNZ0058-001X SD CARD CONNECTOR
OT1 LY43779-001A SPACER(MON.PWB)
******************************
LCD BL BOARD ASSEMBLY <03>
PW YB10325C LCD BL BOARD ASSY
IC751 MIP805 IC
Q7501 2SD1664/QR/-W TRANSISTOR
Q7502 2SD1664/QR/-W TRANSISTOR
Q7503 DTA144EE DIGI TRANSISTOR
or RN2104 DIGI TRANSISTOR
or UN9113J DIGI TRANSISTOR
Q7504 2SC4617/QR/-X TRANSISTOR
or 2SD2216J/QR/-X TRANSISTOR
or 2SC4738/YG/-X TRANSISTOR
D751 1SS376 DIODE
R751 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R7501 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R7502 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R7503 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R7506 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R7507 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R7511 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
C751 NBE20JM-106X T CAPACITOR 10µF,6.3V
C752 NBE20JM-106X T CAPACITOR 10µF,6.3V
C753 NCB31HK-222X CAPACITOR 0.0022µF,50V
C754 NCB31HK-222X CAPACITOR 0.0022µF,50V
C7501 NCZ1016-180X CAPACITOR 18pF,2kV
C7503 NCB31EK-273X CAPACITOR 0.027µF,25V
C7504 NCB31EK-103X CAPACITOR 0.01µF,25V
C7505 NBE20JM-106X T CAPACITOR 10µF,6.3V
L751 NQLZ011-681X COIL 680µH
L752 NQL315K-100X COIL 10µH
L7501 NQLZ010-680X COIL 68µH
T7501 NQS0048-001X SW TRANSF
CN751 QGF0506F2-32X FPC CONNECTOR
CN752 QGF0505F1-24X FPC CONNECTOR
CN753 QGA5002F1-02X CONNECTOR
CN754 QGF0505F2-06X FPC CONNECTOR
! F751 NMFZ007-R20X-K FUSE T0.2A,50V
! F7501 NMFZ007-R40X-K FUSE T0.4A,50V
OT1 LY41726-001A PLATE(EARTH)
******************************
CCD BOARD ASSEMBLY <04>
PW YB20914C-01 CCD BOARD ASSY
Q5201 2SC3931/CD/-X TRANSISTOR
Q5202 2SC4081/RS/-X TRANSISTOR
Q5203 2SC3931/CD/-X TRANSISTOR
R5201 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R5202 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5203 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R5204 NRS181J-0R0X MG RESISTOR 0Ø,1/8W
R5205 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R5206 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5207 NRSA63J-123X MG RESISTOR 12kØ,1/16W
R5208 NRSA63J-102X MG RESISTOR 1kØ,1/16W
C5201 NCB21CK-104X CAPACITOR 0.1µF,16V
C5202 NBP41DM-106X T CAPACITOR 10µF,20V
C5203 NCB21CK-104X CAPACITOR 0.1µF,16V
C5204 NBE21AM-106X T CAPACITOR 10µF,10V
C5205 NCB11EK-104X CAPACITOR 0.1µF,25V
C5206 NCB21CK-104X CAPACITOR 0.1µF,16V
C5207 NCB31EK-222X CAPACITOR 0.0022µF,25V
C5211 NCB21CK-105X CAPACITOR 1µF,16V
L5201 NQL315K-100X COIL 10µH
