5-21
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C7010 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7011 NCB31HK-102X CAPACITOR 0.001µF,50V
C7012 NCB31EK-103X CAPACITOR 0.01µF,25V
C7013 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7014 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7015 NCB31EK-103X CAPACITOR 0.01µF,25V
C7016 NCB11CK-475X CAPACITOR 4.7µF,16V
C7017 NCB10JK-106X CAPACITOR 10µF,6.3V
L7001 NQL38DK-100X COIL 10µH
L7002 NQL38DK-100X COIL 10µH
CN7001 QGF0517F1-06X FPC CONNECTOR
CN7002 QGF0517F2-20X FPC CONNECTOR
******************************
DSC BOARD ASSEMBLY <10>
PW YB20931F-01 DSC BOARD ASSY
IC8001 TMS320DSC24GHK IC
or TMX320DSC24GHK IC
IC8002 K4S643232E-TC60 IC
IC8003 MBV160TE90PTA29 IC(MICRO C ROM)
IC8004 S-80842ANNP-W IC
IC8006 BU2288FV IC
IC8007 MM1385EN IC
Q8001 DTA114EE DIGI TRANSISTOR
Q8002 2SA1774/QR/-X TRANSISTOR
D8001 RB751V-40-X SB DIODE
R8001 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8002 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8003 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8005 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8006 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W
R8007 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R8009 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R8016 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8017 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8020 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8022 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8025 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8026 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8027 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W
R8028 NRS181J-270X MG RESISTOR 27Ø,1/8W
R8029 NRS181J-270X MG RESISTOR 27Ø,1/8W
R8030 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8031 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8032 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8034 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8036 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R8037 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R8038 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8043 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8046 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8048 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8050 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8051 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8053 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8054 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8055 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8058 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8061 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8062 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8063 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8065 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R8066 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R8068 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W
R8070 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W
R8075 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
RA8001 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8002 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8003 NRZ0034-101W NETWORK RESISTOR 100Ø
RA8004 NRZ0034-101W NETWORK RESISTOR 100Ø
C8001 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8002 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8003 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8004 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8005 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8006 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8007 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8008 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8010 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8011 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8014 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8015 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8016 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8017 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8018 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8019 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8020 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8021 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8022 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8023 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8024 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8025 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8026 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8027 NCB30JK-105X CAPACITOR 1µF,6.3V
C8028 NCBA1AK-104W CAPACITOR 0.1µF,10V
C8029 NBE20JM-106X T CAPACITOR 10µF,6.3V
C8030 NCBA1CK-103W CAPACITOR 0.01µF,16V
L8001 NQR0129-002X FERRITE BEAD
L8002 NQR0129-002X FERRITE BEAD
L8003 NQR0129-002X FERRITE BEAD
L8004 NQR0129-002X FERRITE BEAD
L8005 NQR0129-002X FERRITE BEAD
L8006 NQR0129-002X FERRITE BEAD
X8002 NAX0398-001X C OSCILLATOR
CN8001 QGB0501M1-A0X CONNECTOR
CN8002 QGF0508F1-10X FPC CONNECTOR
OT1 LY30029-0X3A SPACER(A)
(Sanwa)-M2D229
GR-DVL765EG-X
E. & O. E. No. 86670
