The following table indicate main different points between models GR-DVL765EG-X, GR-DVL820A, GR-DVL820A-S,

GR-DVL820EA, GR-DVL820SH, GR-DVL1020A, GR-DVL1020EA and GR-DVL1020SH.

The following table indicate different parts number between models GR-DVL765EG-X, GR-DVL820A, GR-DVL820A-S,

GR-DV820EA, GR-DVL820SH, GR-DVL1020A, GR-DVL1020EA and GR-DVL1020SH.

PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.

MODEL

GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH

ITEM

LCD MONITOR 2.5” 3.5”

VIEW FINDER B/W COLOR

DV TERMINAL OUTPUT ONLY IN/OUT

TOTAL ZOOM RATIO 500X 700X 700X 700X

REF.

MODEL

GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH

NO.

ITEM

FINAL ASSEMBLY <M2>

101 UPPER CASE ASSY LY20774-005B

LY20774-005C

* *

LY20797-004C

101A TOP COVER LY20775-001A LY20776-001A

101E COVER(SD) LY32375-001A

LY32375-001B

* * * * * *

101J

EARTH SHEET/BRAKET(EARTH)

LY43540-001A

LY32886-001A

* * *

LY32887-001A

101M SPECIAL SCREW,X2 LY30018-084A LY30018-038A

120 STICKER(SIDE) LY43566-005A LY43566-003A

122 SPACER(A) —

LY30029-0Y5A

* * *

—

LY30029-0Y5A

140 LOWER CASE ASSY LY20769-004D LY20769-003E

140B COVER(DC) LY32364-001A

LY32364-001B

* * * * * *

144 PLATE(ADJUST) LY43256-001A

LY43256-001B

* * * * * *

252 SPACER(A) — — LY30029-0Z7A

REF.

MODEL

GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH

NO.

ITEM

ELECTRONIC VIEWFINDER ASSEMBLY <M4>

300 C.VF ASSY —————LY20838-003A

301

EYE CUP/EYE PIECE ASSY

LY32349-001A PTY20712-001

302

CASE A(VF)/TOP CASE SUB ASSY

LY20766-001A PTY20712-011

303 BOTTOM CASE —————PTY20712-021

304 CAP(VF) LY32351-001A PTY20712-022

305

VF HINGE ASSY/HINGE ASSY

LY20824-001B PTY20838-031

306 LCD MODULE/LCD ASSY QLD0193-001 PTY20712-041

307 FPC QAL0380-002 QAL0287-001

308 SPECIAL SCREW,X4 —————LY30018-063A

309 SPECIAL SCREW,X3 LY30018-0F1A LY30018-055A

310 SPECIAL SCREW,X2 —————LY30018-035A

311 SCREW —————PTY20712-051

321 CASE B(VF) LY20767-001A ———

322 SPECIAL SCREW LY30019-037A ———

323 LEVER(VF) LY43231-001A ———

324 LENS ASSY LY32472-001A ———

324A LENS(A) LY43356-001A ———

324B LENS(B) LY43357-001A ———

325 SPRING(VF) LY43404-001A ———

331 SHEET LY43236-001A ———

332 SHEET2(POLA) LY43246-001A ———

333 HOLDER LCD(VF) LY32347-001A ———

334 SHEET(CUSION) LY43245-001A ———

335 SHEET1(POLA) LY43234-001A ———

336 SHEET(VF) LY43232-001A ———

337 SHEET(DIFF) LY43235-001A ———

338 HOLDER(LED) LY43238-001A ———

339 GUIDE(VF),X2 LY43239-001A ———

340 SPECIAL SCREW,X4 LY30018-060A ———

341 SPACER(A) LY30029-0U6A ———

343 BRACKET(VF) —————LY43827-001A

REF.

MODEL

GR-DVL765EG-X GR-DVL820A GR-DVL820A-S GR-DVL820EA GR-DVL820SH GR-DVL1020A GR-DVL1020EA GR-DVL1020SH

NO.

ITEM

Notes : Mark is same as left. Mark — is not used. Mark * reference model was also changed.

TABLE OF CONTENTS

DIFFERENT TABLE ................................................................................................................................................................................................... 1 to 2

4. CHARTS AND DIAGRAMS (4-1 to 4-6)

4.1 MAIN CIRCUIT BOARD [GR-DVL1020EA/SH]....................................................................................................................................................... 4-1

5. PARTS LIST (5-1 to 5-17)

5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ................................................................................................................................................... 5-1

5.2 FINAL ASSEMBLY <M2> ........................................................................................................................................................................................ 5-3

5.3 ELECTRONIC VIEWFINDER ASSEMBLY <M4> [GR-DVL1020A/EA/SH] ............................................................................................................. 5-6

5.4 MONITOR ASSEMBLY <M5> [GR-DVL820A/A-S/EA/SH] ..................................................................................................................................... 5-7

5.4 MONITOR ASSEMBLY <M5> [GR-DVL1020A/EA/SH] .......................................................................................................................................... 5-8

5.5 ELECTRICAL PARTS LIST ..................................................................................................................................................................................... 5-9

MAIN BOARD ASSEMBLY <01> ............................................................................................................................................................................ 5-9

1 PACKING CASE LY32567-021A LY32567-017A LY32567-008A LY32567-019A

3 POLY BAG LY30023-008A

LY30023-022A

* * * * * *

7 SHEET(AGREMENT) LYT0934-001A ———

8 SHEET(E.UE) LYT0889-010A —————BT-56001-2 —

13 SHEET(CON.PLUG) — LYT0609-001A — — LYT0609-001A — —

14 SER.NET CARD — — — BT-56002-2 — — BT-56002-2 —

26 POWER CORD

QMPL120-190-JR QMPS110-190-JR QMPH020-190-JR QMPL120-190-JR QMPH020-190-JR QMPL120-190-JR

29 CONVERSION PLUG — PEMC1012-02 PEMC1012 — QAM0001-001 PEMC1012-02 — QAM0001-001

34 CD ROM ASSY LY32210-023A LY32210-038A
