# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

5-9

******************************

MAIN BOARD ASSEMBLY <01>

PW YB10391PD-01 MAIN BOARD ASSY,A,B,C,D,E

YB10391QD-03 MAIN BOARD ASSY,F,G

IC1001 UPD703039F1-A27 IC(MICRO C ROM)

or UPD70F3040F1A27 IC(MICRO C ROM)

IC1002 RS5C314 IC

IC1003 X25330S8I-2.5-X IC

or 25LC640-I/SN-X IC

or AT25320N-10SI-X IC

or CAT25C32SI IC

IC1004 TC75S56FU IC

IC1005 TC7S00FU IC

or SN74AHC1G00K IC

IC1006 MB90097PFV145 IC(MICRO C ROM)

IC1007 SN74AHC1G08K IC

IC1008 IC-PST3423U-X IC

IC1009 TC7W08FU IC(DIGITAL)

or SN74AHC2G08T IC

IC1401 UPD703040YF-M06 IC(MICRO C ROM)

or UPD70F3040YFM06 IC(MICRO C ROM)

IC1601 BD6631KV IC

IC1602 TC7W14FU IC(DIGITAL)

or SN74AHC2G14T IC

IC2001 AK4560AVQ IC

IC2501 AK4550VT IC

IC3001 JCY0152 IC

IC3002 BU2501FV IC

IC3004 MC74VHC1G04DF-X IC,E,G

IC3005 JCY0136 IC,A,B,C,D,E

IC3007 JCY0174 IC,F,G

IC3501 JCY0132 IC

IC3502 SN74AHC1G04K IC

IC3701 BA7665FS IC

IC3731 MM1504XN IC

IC3801 JCP8045 IC(DIGITAL)

IC4201 HD49334HF IC

or HD49334AHF IC

IC4202 RH5RZ31CA IC

IC4301 JCY0160-2 IC

IC4302 R1160N151B IC

IC4303 MM1385NN IC

IC4802 TA75W01FU IC

IC4803 TA75W01FU IC

IC4804 LM358DR2 IC

IC4851 UPD16879GS IC

IC5001 CXD3602R IC

IC5002 W194-70G-X IC

IC5003 MM1385DN IC

IC6001 S-80842ANNP-W IC

or S-80842CNNB-W IC

IC6101 FA3698F IC

Q1001 DTC124EE DIGI TRANSISTOR

or UN9212J DIGI TRANSISTOR

Q1002 2SC4617/QR/-X TRANSISTOR

or 2SD2216J/QR/-X TRANSISTOR

Q1003 DTC143EE DIGI TRANSISTOR

or UN921LJ DIGI TRANSISTOR

Q1004 DTC143XE DIGI TRANSISTOR

Q1005 2SJ347 MOS FET

Q1006 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1007 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q1008 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1009 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q1401 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or RN2102 DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1402 UMC3N DIGI TRANSISTOR

Q1403 UMC3N DIGI TRANSISTOR

Q1601 UMC3N DIGI TRANSISTOR

Q2001 UMX1N PAIR TRANSISTOR

Q2002 2SC4617/RS/-X TRANSISTOR

or 2SD2216J/RS/-X TRANSISTOR

Q2501 UMX18N PAIR TRANSISTOR

Q3001 2SC4617/RS/-X TRANSISTOR,A,B,C,D,E

Q3002 2SC4617/RS/-X TRANSISTOR,A,B,C,D,E

Q3701 UMT1N PAIR TRANSISTOR

or XP4401 TRANSISTOR

Q3702 UMZ1N PAIR TRANSISTOR

or XP4601 TRANSISTOR

Q3703 2SA1774/RS/-X TRANSISTOR

Q3704 2SA1774/RS/-X TRANSISTOR

Q3705 UMT1N PAIR TRANSISTOR

or XP4401 TRANSISTOR

Q3731 2SC4617/RS/-X TRANSISTOR

or 2SD2216J/RS/-X TRANSISTOR

Q3732 DTC144EE DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q3733 UMZ1N PAIR TRANSISTOR

or XP4601 TRANSISTOR

Q3734 2SC4617/RS/-X TRANSISTOR

or 2SD2216J/RS/-X TRANSISTOR

Q3735 UMZ1N PAIR TRANSISTOR

or XP4601 TRANSISTOR

Q4801 2SC4655/BC/-X TRANSISTOR

Q4802 2SC4617/RS/-X TRANSISTOR

Q4803 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q4804 DTA144EE DIGI TRANSISTOR

or PDTA144EE DIGI TRANSISTOR

or RN2104 DIGI TRANSISTOR

or UN9113J DIGI TRANSISTOR

Q4805 DTA143EE DIGI TRANSISTOR

or RN2101 DIGI TRANSISTOR

or UN911LJ DIGI TRANSISTOR

Q4806 2SC4617/RS/-X TRANSISTOR

Q4851 2SC4617/RS/-X TRANSISTOR

Q6001 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q6002 MCH6613 MOS FET

Q6004 2SB1188/QR/-W TRANSISTOR

5.5 ELECTRICAL PARTS LIST
