5-20
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
******************************
JUNCTION BOARD ASSEMBLY <05>
PW YB10358A-01 JUNCTION BOARD ASSY
SW571 NSW0120-002X PUSH SWITCH,OPEN EJECT
CN571 QGF0508F1-33X FPC CONNECTOR
CN572 QGF0507F3-15X FFC/FPC CONNECTOR
CN573 QGF0505F2-11X FPC CONNECTOR
CN574 QGF0505F2-06X FPC CONNECTOR
******************************
JACK BOARD ASSEMBLY <06>
PW YB10357B-01 JACK BOARD ASSY
IC501 BA10358F-XE IC
IC502 RPM7138-V4 IR DETECT UNIT
Q501 RPM-22PB PHOTO TRANSISTOR
D501 SML-010LT-X LE DIODE
D502 MA8068 ZENER DIODE
D504 MA8068 ZENER DIODE
D505 MA8068 ZENER DIODE
D506 EMZ6.8N ZENER DIODE
R501 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R502 NRSA63J-684X MG RESISTOR 680kØ,1/16W
R503 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R504 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R505 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R506 NRSA63J-824X MG RESISTOR 820kØ,1/16W
R507 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R508 NRSA63J-683X MG RESISTOR 68kØ,1/16W
R509 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W
R510 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R511 NRSA63J-302X MG RESISTOR 3kØ,1/16W
R512 NRSA63J-470X MG RESISTOR 47Ø,1/16W
R513 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R514 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R515 NQL0022-005X FERRITE BEAD
R516 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R517 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R518 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R519 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R520 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R521 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
C501 NBE21AM-335X T CAPACITOR 3.3µF,10V
C502 NCF31CZ-104X CAPACITOR 0.1µF,16V
C503 NCB31EK-153X CAPACITOR 0.015µF,25V
C504 NCB31EK-153X CAPACITOR 0.015µF,25V
C506 NBE21AM-106X T CAPACITOR 10µF,10V
C509 NBE20JM-226X T CAPACITOR 22µF,6.3V
C514 NCB31HK-103X CAPACITOR 0.01µF,50V
C515 NCB31HK-103X CAPACITOR 0.01µF,50V
L501 NQR0251-004X FERRITE BEAD
L502 NQR0251-004X FERRITE BEAD
L503 NQR0251-004X FERRITE BEAD
L504 NQR0251-004X FERRITE BEAD
L505 NQR0251-004X FERRITE BEAD
L506 NQR0251-004X FERRITE BEAD
J501 QNS0078-001 3.5 JACK
J502 QNS0005-001 3.5 JACK
J503 PEMC1203 MINI JACK
CN501 QGF0503C1-06V FFC/FPC CONNECTOR
CN502 QGF0508F1-24X FPC CONNECTOR
OT1 LY43515-001A SHEET(IR)
******************************
REAR BOARD ASSEMBLY <07>
PW YB10362B-01 REAR BOARD ASSY
D553 MA8068 ZENER DIODE
R551 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R552 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R553 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R554 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R557 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R558 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R559 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R560 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R561 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
C551 NCF31CZ-104X CAPACITOR 0.1µF,16V
WR1 WJT0064-001A E-CARD WIRE,CN551-MAIN CN103
J551 QNZ0557-001 D CONNECTOR
J553 QNZ0497-001 USB CONNECTOR
J554 QNA0027-001 DC JACK
CN551 QGF0507F3-12X FFC/FPC CONNECTOR
CN552 QGA1002F1-06X CONNECTOR
******************************
B/W VF BOARD ASSEMBLY <08>
PW YB20910B B/W VF BOARD ASSY
IC7001 MCVVQ111FB IC
Q7001 PUMX1 PAIR TRANSISTOR
D7001 NSCW100A0/ST/-X LE DIODE
D7002 MA111 DIODE
R7001 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R7002 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R7003 NRSA63J-183X MG RESISTOR 18kØ,1/16W
R7004 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7006 NRVA63D-333X CMF RESISTOR 33kØ,1/16W
R7007 NRVA63D-153X CMF RESISTOR 15kØ,1/16W
R7008 NRVA63D-473X CMF RESISTOR 47kØ,1/16W
R7009 NRSA63J-682X MG RESISTOR 6.8kØ,1/16W
R7010 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R7011 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R7012 NRSA63J-561X MG RESISTOR 560Ø,1/16W
R7013 NRSA63J-470X MG RESISTOR 47Ø,1/16W
VR7001 NVP0016-223X TRIM RESISTOR,GAIN
C7001 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7002 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7003 NCB21AK-105X CAPACITOR 1µF,10V
C7004 NCB31EK-223X CAPACITOR 0.022µF,25V
C7005 NCB31EK-103X CAPACITOR 0.01µF,25V
C7006 NCF21CZ-105X CAPACITOR 1µF,16V
C7007 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7008 NCF31CZ-104X CAPACITOR 0.1µF,16V
C7009 NCF31CZ-104X CAPACITOR 0.1µF,16V
